i.MX 8 SOMs

This system-on-module (SOM) series, based on NXP Semiconductor’s i.MX 8, is ideal for advanced graphics, imaging, machine learning, machine vision, audio, voice, and video applications. Based on decades of embedded device and wireless connectivity expertise, this line of SOMs is the ideal platform for your IoT designs. It delivers powerful MPU/MCU, endless interfaces, 4-core virtualization, 10+ year lifecycle, smart power management, and Secure Enclave/Secure Boot. All SOMs are well supported with advanced development kits, documentation, software, firmware, and dedicated FAE support teams, all of which are readily available to help speed development.


SOM i.MX 8 Portfolio

  • Chipset (MPU)
    4x Cortex®-A53 cores @ up to 1.8 GHz (NXP i.MX 8M Mini)
    Chipset (MCU)
    1x Cortex®-M4 core @ 400 MHz (NXP i.MX 8M Mini)
    Wireless Specification
    (optional)
    Wi-Fi 6/6E
    Bluetooth 5.3/5.4
    Dimension (Length - mm)
    82
    Dimension (Width - mm)
    50
    Memory
    1GB, 2GB, or 4GB LPDDR4
    Form Factor
    SMARC Connector
    Learn More
  • Chipset (MPU)
    4x Cortex®-A53 cores @ 1.8 GHz (NXP i.MX 8M Plus SMARC)
    Chipset (MCU)
    1x Cortex®-M7 core @ 800 MHz (NXP i.MX 8M Plus SMARC)
    Wireless Specification
    (optional)
    Wi-Fi 6/6E
    Bluetooth 5.3/5.4
    Dimension (Length - mm)
    82
    Dimension (Width - mm)
    50
    Memory
    2GB or 4GB LPDDR4
    Up to 8GB (MOQ required)
    Form Factor
    SMARC Connector
    Learn More
  • Chipset (MPU)
    2x Cortex®-A35 cores @ up to 800 MHz
    Chipset (MCU)
    1x Cortex®-M33F core @ 216 MHz
    Dimension (Length - mm)
    51
    Dimension (Width - mm)
    32
    I2C
    7x I2C
    Learn More
  • Chipset (MPU)
    4x Cortex®-A53 cores @ 1.6 GHz
    (NXP I.MX 8M Plus)
    Chipset (MCU)
    1x Cortex®-M7 core @ 800 MHz
    (NXP I.MX 8M Plus)
    Wireless Specification
    Wi-Fi 5 (802.11ac)
    Bluetooth 5.3
    Chipset (Wireless)
    NXP 88W8997
    Dimensions
    40 x 47 x 4.6 mm
    Learn More
  • Chipset (MPU)
    4x Cortex®-A53 cores @ 1.8 GHz (NXP i.MX 8M Plus)
    Chipset (MCU)
    1x Cortex®-M7 core @ 800 MHz (NXP i.MX 8M Plus)
    Wireless Specification
    Wi-Fi 5 (802.11ac)
    Bluetooth 5.0
    Dimension (Length - mm)
    48
    Dimension (Width - mm)
    38
    Learn More
  • Chipset (MPU)
    4x Cortex®-A53 cores @ 1.8 GHz (NXP i.MX 8M Mini)
    Chipset (MCU)
    1x Cortex®-M4F core (NXP i.MX 8M Mini)
    Wireless Specification
    Wi-Fi 5 (802.11ac)
    Bluetooth 5.0
    Dimension (Length - mm)
    69.6
    Dimension (Width - mm)
    40
    Learn More
  • Chipset (MPU)
    4x Cortex®-A53 cores @ 1.5 GHz (NXP i.MX 8M Nano)
    Chipset (MCU)
    1x Cortex®-M7 core @ 600 MHz (NXP i.MX 8M Nano)
    Wireless Specification
    Wi-Fi 5 (802.11ac)
    Bluetooth 5.0
    Dimension (Length - mm)
    69.6
    Dimension (Width - mm)
    40
    Learn More
  • Chipset (MPU)
    4x Cortex®-A53 cores @ 1.6 GHz
    (NXP I.MX 8M)
    Chipset (MCU)
    1x Cortex®-M7 core @ 800 MHz
    (NXP I.MX 8M)
    Wireless Specification
    Wi-Fi 5 (802.11ac)
    Bluetooth 5.3
    Dimension (Length - mm)
    67.6
    Dimension (Width - mm)
    48.4
    Learn More

Custom Solutions

Reduce design risk and accelerate your time to market with Ezurio's custom Single Board Computers (SBC). We offer:

  • A hand-in-hand partnership approach.
  • Design your board your way.
  • Lower production costs by choosing your required components.
  • Industry leading hardware and software.

Learn More

Custom SBC for SOM pages.png

Manage every part of the security lifecycle.
Find the options you need in the Summit Suite range.

Learn More

Ezurio (formerly Laird Connectivity) is an NXP Gold Partner

Ezurio is honored to be approved as an NXP Gold Partner. We look forward to working with the NXP team to deliver the solutions our customers need in an ever changing processor and wireless future.

Learn More


More Than a Module A Comprehensive Hardware and Software Solution

With decades of experience in the development and production of complex embedded and wireless products, we are the ideal SOM provider to help you bring your application to market smarter and faster.

Secure

  • Secure enclave
  • Secure and encrypted boot
  • FIPS 140-2 and 140-3 Level 1 Validations
  • Long Term Linux Support with CVE remediation

High-Performance

  • Powerful heterogenous multiprocessing
  • Dedicated machine learning
  • Dedicated graphics, video, and audio hardware
  • Diversity of hardware interfaces
  • Power efficient
  • Virtualization
  • Advanced development kits

Flexible

  • Long term hardware availability
  • Hardware connectivity roadmap
  • Comprehensive software support
  • Device management support
  • Full product lifecycle management

What Makes Us Different?

On-Site EMC and Antenna Testing

The only module and antenna manufacturer that offers our own on-site EMC testing approvals, which drastically reduces your risk and time to market. Let our onsite EMC Test engineers help you navigate the EMC certification process.

Learn More


IoT Solutions

Whether you need a product tailored, customized or are looking for complete product development services, we use in-house expertise and strategic partnerships to bring your product to market faster with the results you want.

Learn More


Antenna Options

We offer a broad portfolio of cost-effective embedded antenna solutions that provide unmatched connectivity for your wireless devices. Let us help you find the right antenna pre-certified with our extensive module selection.

Learn More


Endless Applications

  • Industrial

    Industrial

  • Security Systems

    Security Systems

  • Building Automation

    Building Automation

  • Medical Devices

    Medical Devices
