455-00055

Sentrius RG1xx
    Contact Us

    Specifications

    Accessories
    N/A
    Additional Description
    Sentrius RG1xx Gateway 923 MHz, including LoRaWAN, Wi-Fi & Ethernet
    Antenna Type
    External
    Chipset (Wireless)
    Semtech SX1301/1257, CSR8811 A08, QCA6004
    Frequency Range (Max)
    2483 MHz
    Frequency Range (Min)
    2400 MHz
    Frequency Range 2 (Max)
    5825 MHz
    Frequency Range 2 (Min)
    5150 MHz
    Frequency Range 3 (Max)
    927.8 MHz
    Frequency Range 3 (Min)
    916 MHz
    Information
    It is not possible to switch/reconfigure the supported region after purchase
    Logical Interfaces
    Ethernet
    OS/Software
    Web-based Interface (WebLCM)
    Part Group
    Standard RG1xx (Wi-Fi / LoRa / Ethernet)
    Product Type
    IoT Gateway
    Region
    New Zealand (NZ)
    System Architecture
    Hostless
    Technology
    802.11abgn, LoRaWAN

    Documentation

    Name Part Type Last Updated
    Product Brief - Sentrius RG1xx Series Gateway 455-00055 Product Brief 03/21/2023
    Overview - Understanding LoRa 455-00055 Documentation 02/28/2019
    AS/NZS Certifications - RG191 455-00055 Certification 12/18/2020
    Quick Start Guide - Sentrius RG1xx 455-00055 Documentation 07/31/2024
    Application Note - Setting up Basic station on the Things Stack v3 455-00055 Application Note 08/09/2021
    Application Note - Setting up Basic Station on The Things Network (TTN v2) 455-00055 Application Note 05/06/2021
    Application Note - Setting Up Basics Station on ChirpStack 455-00055 Application Note 08/20/2020
    PCN 3A-2020 – RG1xx 455-00055 Documentation 04/27/2020
    Application Note - RG1xx AWS IoT Core for LoRaWAN 455-00055 Application Note 09/05/2023
    PCN_11A-2022 - RG1xx 455-00055 Documentation 11/11/2022

    Buy Now

    Distributor Part In Stock Region Buy
    Mouser 455-00055 12 North America Buy Now
    DigiKey 455-00055 5 North America Buy Now
    Arrow Electronics 455-00055 0 North America Buy Now


    FAQ

    Can I really expect 15 km distance transmission using LoRaWAN in my day to day application operation?

    All Ezurio (formerly Laird Connectivity) LoRa products should be referred as LoRaWAN as they all supports its protocol. LoRaWAN protocol make use of LoRa Chirp Spectrum Modulation within a license-free sub-gigahertz frequency band that allow to transmit regularly small packets up to 15km.

    It’s important to consider that 15km can only be achieved within absolute best conditions, some of which would be an outdoor “line of sight” transmission, interference free environment, ideal humidity/temperature, highest Spreading Factor, ect… Such range magnitude cannot represent any “real world” distance transmission and shouldn’t be expected by default.
